MS Reducer

Get a Price/Quote

MOQ : 100 Units

MS Reducer Specification

Connection Type
Butt Weld

Diameter
As specified (matches pipe dimension)

Tensile Strength
370 MPa (min)

Temperature Range
-20C to 450C

Coating Type
Optional (Zinc, Epoxy, Custom)

Flexibility
Rigid

Sealing Type
Metal-to-metal

Tolerance
0.03 mm

Yield Strength
240 MPa (min)

Bend Radius
Standard as per fitting size

Product Type
Other

Material
Mild Steel

Connection
Welded

Shape
Concentric / Eccentric

Standard
ASME/ANSI B16.9, DIN, EN, JIS

Surface Treatment
Other

Outer Diameter
1/2 to 36 (or as required)

Section Shape
Round

Length
Customizable

Thickness
2 mm - 10 mm

Color
Silver

Warranty
Yes

Usage
Pipeline fitting, Industrial, Plumbing

Rated Pressure
Sch 10 to Sch 160 / PN6 - PN40

Application
Connects pipes of different diameters in industries such as oil & gas, water supply, chemical, and power plants

Material Grade
IS 2062, ASTM A234 WPB

Packaging Type
Wooden Cases / Pallets / Custom

Corrosion Resistance
Good due to surface treatment

End Type
Beveled Ends

Inspection
100% Dimensional and Visual Inspection

Manufacturing Process
Seamless / Welded

Lead Time
2-4 Weeks

MS Reducer Trade Information

Minimum Order Quantity
100 Units

Supply Ability
1000 Units Per Day

Delivery Time
5 Days

Main Domestic Market
All India

About MS Reducer

MS reducer is a pipe fitting used to join two pipes of different sizes. As a result, it reduces the size of the pipes in the system, switching between sizes. It is designed especially for connecting pipes of various sizes. In order to provide the most connection flexibility when connecting fractional tubes in different installations, this product is employed in a variety of industries. MS reducer is basically an element of a piping system that alters the pipe size from a bigger to a smaller bore. It also enables a change in pipe size to accommodate existing pipework.

Precision Engineering for Diverse Applications

Our MS Reducers are engineered for adaptability in pipeline fittings across several industries, including oil and gas, water supply, power generation, and chemical processing. With a robust material grade and precision tolerances, these reducers ensure secure and efficient transitions between pipes of varying diameters. Their standardized dimensions and customizable lengths make them ideal for projects requiring strict compliance and reliable performance.

Quality Assurance and Customization

Each reducer undergoes a thorough 100% visual and dimensional inspection to guarantee consistency with international standards. The surface is treated to enhance corrosion resistance, ensuring longevity in aggressive environments. Customers can select from a range of thicknesses, diameters, and optional coatings (zinc, epoxy, or custom) to match specific project demands, all supplied in protective wooden or custom packaging.

FAQ's of MS Reducer:

Q: How are MS Reducers with beveled ends typically manufactured?

A: These reducers are manufactured using either seamless or welded processes, adhering to recognized standards like ASME/ANSI B16.9, DIN, EN, and JIS. Each reducer undergoes a comprehensive dimensional and visual inspection, ensuring precision and mechanical integrity.

Q: What is the primary application of these MS Reducers?

A: MS Reducers are widely used to connect pipes of differing diameters in applications such as oil and gas transmission, water supply systems, chemical processing, power plants, and general industrial plumbing.

Q: When should I use a concentric versus an eccentric reducer?

A: A concentric reducer is typically chosen when maintaining a common centerline is important, such as in vertical piping. Eccentric reducers are preferred in horizontal pipelines to prevent air accumulation by keeping the pipeline level at the base.

Q: Where are MS Reducers commonly installed?

A: They are commonly installed in pipeline systems within facilities like refineries, water treatment plants, chemical factories, and power generation stations-wherever pipelines must be joined securely and reliably.

Q: What are the benefits of the surface treatment and optional coatings?

A: The surface treatment provides good corrosion resistance, extending the reducer's service life. Optional coatings such as zinc or epoxy add further protection against harsh environmental conditions, ensuring long-term reliability.

Q: How is the product packaged and delivered?

A: Reducers are securely packed in wooden cases, pallets, or custom packaging to protect against transport damage. The usual lead time for delivery is 2-4 weeks, depending on quantity and customization.

Q: What quality checks are performed before shipping?

A: A 100% dimensional and visual inspection is conducted to ensure that each reducer meets the specified tolerances and quality standards, guaranteeing consistent performance and fit within your piping system.
